Numark iDJ3 Service Manual

..2
AL2-51-4401 TRANSISTOR 2N4401 NPN (MMBT4401LT1 )
2
Q1,3
..2
AL2-51-4403 TRANSISTOR 2N4403 PNP
5
Q2,4~7
..2
AL2-52-5242 DIODE MMBZ5242B
1
D5
..2
AL2-54-6306 MOSFET FDC6306P P-CH
2
U7,14
..2
AL2-61-2985 IC LP2985IM5-40
1
U1
..2
AL2-61-7223 IC NJU7223DL1-33 3.3V
1
U10
..2
AL2-75-4345 IC CS4345
2
U4,11
..2
AL2-85-0403 IC TPS60403
2
U2,3
..2
AL4-08-0402 Con USB 4-Pin Female PC-MNT Horizontal
1
J12
..2
AL7-01-0046 Crystal 12MHZ 49US SMD Fundamental
1
X4
..2
AL7-20-0071 BEAD SMD 1806
2
L2,3
..2
CS101J5003NPO CERAMIC 100PF/50V 5% 0603 NPO
2
C92,93
..2 CS104K5003X7R CERAMIC 0.1UF/50V 10% 0603 X7R 43
C4~6,16,22~31,35,36,38,40,45,48,50,53,55,56~59,61,6
2,64,67~70,75,79,81,83,85,90,91,94,96
..2
CS105K1003X5R CERAMIC 1UF/10V 10% 0603 X5R
7
C7~9,20,46,78,84
..2
CS180J5003NPO CERAMIC 18PF/50V 5% 0603 NPO
6
C12~15,74,82
..2
CS200J5003NPO CERAMIC 20PF/50V 5% 0603 NPO
2
C39,49
..2
CS331J5003NPO CERAMIC 330PF/50V 5% 0603 NPO
4
C18,33,52,72
..2
CS332K5003X7R CERAMIC 3.3nF/50V 10% 0603 X7R
4
C10,37,51,71
..2
CS475K1606X7R CERAMIC 4.7UF/16V 10% 1206 X7R
4
C1~3,60
..2
DISDBAT54SSM DIODE BAT54S 30V 0.2A SOT-23
2
D1,2
..2
EC47710T Capacitor Electrolytic 470uF/10V 8*12mm
1
C73
..2
ECS10616BP Capacitor Electrolytic 10UF/16V (SMD)
12
C17,32,42,43,54,63,65,66,86,87,95,97
..2
ECS10710D Capacitor Electrolytic 100UF 10V SMD-D
1
C77
..2
ECS22616B Capacitor Electrolytic 22uF/16V B type SMD
11
C11,19,21,34,41,44,47,76,80,88,89
..2
ICISP1583BS IC ISP1583BS
1
U15
..2
ICLM2940IMP-5 IC REG VOLTAGE LM2940+5V
1
U16
..2
ICNJM2112M IC NJM2112M
4
U5,6,12,13
..2
ICUSBLC62SC6 IC USBLC62SC6
1
D8
..2
ICYHFRC158 IC YHFRC158 (LC4032V+PROGRAM)
1
U9
...3
ICLC4032V IC LC4032V
1
-
..2
ICYHFRC159 IC YHFRC159 (ATMEGA162+PROGRAM)
1
U8
...3
ICATMEGA162 IC ATMEGA162
1
-
..2
JKDJ-0702B-020 DC BASE 2.0MM
1
J9
..2
PC10C002 I/O PCB
1
-
..2
RJ1031 RCA Base
1
J11
..2
RS000010J03 RESISTOR 0 5% SMD 0603
5
R2,73,74,88,96
..2
RS001K10F03 RESISTOR 1K 1% SMD 0603
15
R1,6,23,43,44,56,58,59,85,86,98,102,105,107,109
..2
RS001M10F03 RESISTOR 1M 1% SMD 0603
3
R3,4,101
..2
RS002K10F03 RESISTOR 2K 1% SMD 0603
2
R9,40
..2
RS004710F03 RESISTOR 47 1% SMD 0603
5
R10,41,57,66,89
..2
RS010010F03 RESISTOR 100 1% SMD 0603
6
R47,54,70,79,103,104
..2
RS010K10F03 RESISTOR 10K 1% SMD 0603
20
R5,8,19,33,55,60~64,71,72,80~84,99,106,108
..2
RS012K10F03 RESISTOR 12K 1% SMD 0603
1
R92
..2
RS020K10F03 RESISTOR 20K 1% SMD 0603
8
R17,18,20,22,25,28,31,32
..2
RS047010F03 RESISTOR 470 1% SMD 0603
2
R14,15
..2
RS051110F03 RESISTOR 511 1% SMD 0603
1
R91
..2
RS06K210F03 RESISTOR 6.2K 1% SMD 0603
1
R30
..2
RS100K10F03 RESISTOR 100K 1% SMD 0603
2
R7,100
..2
RS10K710F03 RESISTOR 10.7K 1% SMD 0603
4
R16,27,52,68
..2
RS3K2410F03 RESISTOR 3.24K 1% SMD 0603
4
R11,38,51,67
..2
RS475K10F03 RESISTOR 475K 1% SMD 0603
1
R90
..2
RS47K510F03 RESISTOR 47.5K 1% SMD 0603
2
R93,97
..2
RS4K9910F03 RESISTOR 4.99K 1% SMD 0603
3
R13,26,42
..2
RS5K3610F03 RESISTOR 5.36K 1% SMD 0603
6
R12,21,29,39,49,76
..2
RS6K6510F03 RESISTOR 6.65K 1% SMD 0603
4
R48,53,69,77
..2
RS820K10F03 RESISTOR 820K 1% SMD 0603
1
R87
..2
RS9K3110F03 RESISTOR 9.31K 1% SMD 0603
4
R46,50,75,78
..2
TE10200601 6P CONNECTOR
1
(J6)
..2
TE512540801 Pin Header 180° Pitch=2.54mm Single Row 8Pin DIP
1
(J5)
..2
TE562540601 TERMINAL 6P 2.54MM
1
(J4)
..2
TE612000801 8P CONNECTOR
1
(J8)
..2
TE612001201 12P CONNECTOR
1
(J10)
..2
TE622000401 4P CONNECTOR
1
(J2)

Numark iDJ3 Specifications

General

Mixer section	Yes
Product color	Black, Silver
Scratcher type	Digital Vinyl System (DVS) scratcher
USB direct playback	-
Built-in optical drive	No
Number of mixer channels	3 channels
Number of scratcher platters	2
Headphone outputs	1
USB connector type	USB Type-B
Apple docking compatibility	iPhone, iPod
Minimum RAM	0.512 GB
Minimum processor	Pentium 4, AMD Athlon XP
Minimum storage drive space	20 MB
Minimum display resolution requirement	1024 x 768 pixels
Cables included	USB
Bundled software	Virtual DJ LE
