2
Before getting started, install the Cross software:
1. Insert the included software CD into your computer's CD/DVD drive.
2. Open the contents of the CD and double-click "Cross – iDJ3 #.dmg" to begin the software installation. (Note:
instead of "#," the file name will have the software version number).
3. Follow the on-screen instructions.
To start using iDJ3:
1. Connect iDJ3 to an available USB port on your computer. (If possible, use a USB port on the rear panel of your
computer.)
2. Open Cross by double-clicking the icon on your computer's Desktop (if you created a Desktop shortcut) or by
going to Applications MixVibes.
For more information on how to use Cross, see the manual on the CD: Go to Applications MixVibes. The
manual will be a ".pdf" document in the language in which you chose to install the software.
TOP PANEL FEATURES
1. HEADPHONES – Connect your 1/4" headphones to this output for cueing and mix monitoring.
2. MIC INPUT – Connect a 1/4" microphone to this input.
3. MIC GAIN – Adjusts the audio level of the microphone signal.
4. MASTER VOLUME – Adjusts the output volume of the Program mix.
5. CUE VOLUME – Adjusts the audio level of the Cue channel.
6. CUE SOURCE – Selects the audio that is sent to the headphones. Switch it to "MASTER" to hear the
Program mix. Switch it to "A/B" to hear Decks A and B in the Cue channel. Switch it to "iPod" to hear
iPod.
7. A/B CUE – Sends pre-fader audio to the Cue Channel for headphone monitoring.
8. BROWSE KNOB – Turn this knob to scroll through lists of tracks and directories in the software. When
a directory is selected, press the knob to enter it.
9. LOAD A / LOAD B – Press one of these buttons while a track is selected to assign it to Deck A or Deck
B, respectively.
10. CHANNEL FADER – Adjusts the audio level on the corresponding channel.
11. CROSSFADER – Blends audio playing between Decks A and B. Sliding this to the left plays Deck A
and sliding to the right plays Deck B.
