Numark M4 Service Manual

M4 PCB BOM
JP16 JP17 JP18 JP19 JP20
JP21 JP22 JP23 JP24 JP25
JP26 JP27 JP28 JP29 JP30
JP31 JP32
7.5MM 5 JP35 JP36 JP37 JP38 JP39
8.2K 4 R106 R206 R506 R606
10/25 2 C159 C259
10/25(S) 16 C108 C111 C122 C150 C208
C211 C222 C250 C308 C311
C408 C411 C508 C511 C608
C611
10K 4 R132 R133 R232 R233
10MM 19 JP40 JP41 JP42 JP43 JP44
JP45 JP46 JP47 JP48 JP49
JP50 JP51 JP52 JP53 JP54
JP55 JP56 JP57 JP58
12.5MM 8 JP60 JP61 JP62 JP63 JP64
JP65 JP66 JP67
15K 8 R128 R153 R228 R253 R528
R553 R628 R653
15MM 8 JP70 JP71 JP72 JP73 JP74
JP75 JP76 JP77
18K 8 R130 R159 R230 R259 R330
R430 R530 R630
22/25(S) 4 C701 C702 C903 C912
22K 6 R126 R226 R326 R426 R526
R626
22P 4 C151 C251 C711 C712
27K 9 R121 R155 R221 R255 R321
R421 R521 R621 R903
30K 6 R124 R224 R324 R424 R524
R624
33 12 R113 R160 R213 R260 R313
R413 R513 R613 R719 R720
R723 R724
33K 8 R118 R218 R318 R328 R418
R428 R518 R618
39K 2 R705 R706
47/16 10 C105 C106 C205 C206 C505

Numark M4 Specifications

General

Frequency range	20 - 20000 Hz
Channels quantity	3 channels
Channel fader (1kHz)	90 dB
Digital sound processing	- bit
Number of EQ bands per channel	3
Line Signal-to-Noise Ratio (SNR)	100 dB
Microphone input impedance	600 Ω
Balanced line output level	7 V
Record out	1
Line inputs (RCA)	4
Phono inputs (RCA)	2
