6
Operation
Performance Pad Modes
The upper row of pads has different functions depending on their mode: Manual Loop Mode,
Auto Loop Mode, and Sample Mode.
To select a mode, hold down the Pad Mode button and
press one of the upper pads.
An LED under the pad section indicates the currently selected
mode.
Manual Loop Mode: Hold Pad Mode and press the pad marked Manual Loop to assign the
upper 4 pads to the functions listed below:
Loop In: Sets the beginning of a loop. After a Loop Out point is set, when this button is
pressed again, it will allow for fine adjustment of the Loop In point.
Loop Out: Sets the end point for the loop. When this button has been pressed after a Loop
Out point has been set, it will allow for fine adjustment of the Loop Out point.
On/Off: When this is pressed inside a loop, this will turn the loop off. When pressed outside
a loop, this will activate the loop and start playback from its Loop In point. If a loop has not
been set, this button will have no effect.
Loop x1/2: Cuts the currently playing loop in half. Press Shift + Loop x1/2 to double the
length the currently playing loop.
Auto Loop Mode: Hold Pad Mode and press the pad marked Auto Loop to assign the upper
4 pads to the functions listed below:
Auto 1: Sets and starts playback of a 1-beat auto loop. Press Shift + Auto 1 to set and start
playback of a 1/16-beat loop roll.
Auto 2: Sets and starts playback of a 2-beat auto loop. Press Shift + Auto 2 to set and start
playback of a 1/8-beat loop roll.
Auto 4: Sets and starts playback of a 4-beat auto loop. Press Shift + Auto 4 to set and start
playback of a 1/4-beat loop roll.
Auto 8: Sets and starts playback of an 8-beat auto loop. Press Shift + Auto 8 to set and
start playback of a 1/2-beat loop roll.
Sample Mode: Hold Pad Mode and press the pad marked Sampler to assign the upper 4
pads to the functions listed below:
Sample 1: Plays the sample assigned to Sample Pad 1. Press Shift + Sample 1 to stop
playback, or to load a sample if the slot is empty.
Sample 2: Plays the sample assigned to Sample Pad 2. Press Shift + Sample 2 to stop
playback, or to load a sample if the slot is empty.
Sample 3: Plays the sample assigned to Sample Pad 3. Press Shift + Sample 3 to stop
playback, or to load a sample if the slot is empty.
Sample 4: Plays the sample assigned to Sample Pad 4. Press Shift + Sample 4 to stop
playback, or to load a sample if the slot is empty.
Demo Mode
Mixtrack Platinum will automatically enter a demonstration mode after 30 seconds if
connected to a computer via USB without opening the software. To exit Demo Mode, open
the Serato DJ Intro software.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Numark MIXTRACK PLATINUM and is the answer not in the manual?

Numark MIXTRACK PLATINUM Specifications

General IconGeneral
Minimum RAM4 GB
Minimum processorIntel Core i3, i5, i7
Minimum processor speed1.07 GHz
Minimum storage drive space5000 MB
Mac operating systems supportedMac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Windows operating systems supportedWindows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64
Minimum display resolution requirement1280 x 720 pixels
Sample rate44.1 kHz
Platter size5 \
Product colorBlack
Number of drum pads16
Built-in optical driveNo
Number of mixer channels4 channels
Number of scratcher platters2
USB connector typeUSB Type-B
Headphone connectivity3.5 mm/6.35 mm
Microphone connectivity3.5 mm
Apple docking compatibilityNot supported
Number of microphone inputs1
Display typeLCD
Bundled softwareSerato DJ Intro
Power supply typeUSB
