Numark MixTrack Pro FX Service Manual

0.1 PT1110619541 Button(1/2)(Printing) 2 42
..2 PT11106195 KNOB 2
0.1 PT1110619542 Button(X2)(Printing) 2 43
..2 PT11106195 KNOB 2
0.1 PT1110619543 Button (TAP) Printing 1 47
..2 PT11106195 KNOB 1
0.1 PT1110631623 Button(Phone)(Printing) 2 49
..2 PT11106316 Button 2
0.1 PT1110644302 Button(+,-)(Printing) 2 41
..2 PT11106443 Button (two Button) 2
0.1 PT1110649601 KNOB (Painting) 1 1
..2 PT11106496 Knob(LRG) 1
0.1 PT11106555 Light Pipe(5) 2 51
0.1 PT1110657403 Button Assembly(SATIN) 2 38
0.1 PT1110658504 Button(SHIFT) Printing 2 37
..2 PT11106585 Button 2
0.1 PT1110659301 KNOB (Painting) 1 4
..2 PT11106593 Knob(MED) 1
0.1 PT11106603 Knob 7 2
0.1 PT1110666906 Button(LOOP)(Printing) 2 44
..2 PT11106669 Button 2
0.1 PT1110669502 Wheel Lamp(Painting) 2 14
..2 TWPT11106695 Wheel Lamp Ass'y 2
0.1 PT1110673302 Rotate Button(Painting) 2 53
..2 PT11106733 ROTATE BUTTON 2
0.1 PT11106772 Knob (Cool GRAY 10C) 6 5
0.1 PT11106773 VR Knob 2 6
0.1 PT1110677703 Button (1) Printing 1 45
..2 PT11106777 Button 1
0.1 PT1110677704 Button (2) Printing 1 46
..2 PT11106777 Button 1
0.1 PT1110710501 Wheel Frame(Painting) 2 13
..2 TWPT11107105 Wheel Frame Ass'y 2
0.1 PT1110801 Wheel Base 2 24
0.1 PT1130210702 Cabinet(Printing & Painting) 1 35
..2 PT11302107 Cabinet 1
...3 ABS5000 ABS MATERIAL 567
...3 CM-003-MG power
*340.000
0.1 PT1130313101 Bottom Chassis(Printing) 1 28
..2 PT11303131 Bottom Chassis 1
...3 ABS5000 ABS MATERIAL 515
...3 CM-003-MG power
*300.000
0.1 PU005005025A Conductive Foam 2 20
0.1 PU008008008 CONDUCTIVE FOAM 1 82
0.1 PU008008012 Canductive oam 1 81
0.1 RN4100001 CS Ring(10mm) 2 56
0.1 RU1110620303 Rubber Button(FX) 1 48
0.1 RU1110621301 Rubber (PAD)(Printing) 2 39
0.1 RU1530608 Rubber Foot 6 31
0.1 SC0308FBBI Screw M3X8 PFB Tapping 13 11
0.1 SC0308FIBI Screw M3X8 PFB 8 23
0.1 SC0308RBNI Screw M3X8 PRN Tapping 52 26
0.1 SC0310PBBI Screw M3X10 PPB TAPPING 14 30
0.1 SC2604RINI Screw M2.6X4 PPN 2 21
0.1 TWMT112025302 Wheel Axis Assembly 2 25
..2 MT1105591 Wheel Axis 2
..2 MT1105593 Copper 2
..2 MT1120253 Metal Plate(Wheel) 2
0.1 TWPT1110649802 Knob(18.0mm)Assembly 2 7
..2 PT11106498 Knob(18.0mm) 2
..2 PT11106499 Decoretive(18.0mm) 2
..2 PT1130030 Knob Plate(18.0MM)(Black) 2
0.1 WR0320001502 Shielding Cable 3pin Single Ro 1 40

Numark MixTrack Pro FX Specifications

General

Type	DJ Controller
Channels	2
Jog Wheels	2
Software	Serato DJ Lite
Number of Decks	2
EQs	3-Band EQ per channel
Audio Interface	Built-in
Crossfader	Yes
USB Connectivity	USB Type-B
Outputs	RCA stereo output
Headphone Output	1/4" and 1/8"
Mixer	2-channel
Pad Controls	Sampler
Software Compatibility	Serato DJ Lite
Performance Pads	8 per deck
Faders	2 x Volume, 2 x Tempo
