Numark MixTrack Pro FX Service Manual

0.1 WR0720004001 Isolation Cable 7Pin Single Ro 1 59
0.1 WRUSB05200015B2 Shielding Cable USB 2.0 5Pin S 1 50
0.1 WS116010305O Washer 2 32
0.1 TWPC19C02001 Function PCB Integration Asse 1
..2 TWPC19C02001T Function PCB SMT Integration A 1
...3 PC19C020 Function PCB 1
...3 TWPC19C020A01T Right PAD PCB SMT Assembly 1 73
....4 AA822524X IC SN74HC165PW 3 IC2,4,6
....4 CS101J5003NPO CCAP SMD 100pF/50V 5% 0603 NPO 3 C4,9,14
....4 CS104K5003X7R CCAP SMD 0.1uF/50V 10% 0603 X7R 9 C1,2,6,7,11,12,15,16,19
....4 CS105K1603X7R CCAP SMD 1uF/16V 10% 0603 X7R 2 C18,20
....4 CS475K1605X5R CCAP SMD 4.7uF/16V 10% 0805 X5R 1 C17
....4 CS561J5003NPO CCAP SMD 560pF/50V 5% 0603 NPO 2 C5,10
....4 DICM1213A01SO Diode ESD Protection Arrays CM1213A 1 D1
....4 FCN1T1001602
FCN Down Touch ZIF SMD Pitch=1.0mm 16P
1 FCN1
....4 IC74HCT595D IC 74HCT595D 3 IC1,3,5
....4 ICXC6209F452MR IC XC6209F452MR 1 IC7
....4 LDKPT-1608SURCK Liquid-emitting Diode Red SMD 0603 120° 21
LED1,2,3,4,7,8,9,10,11,12,13,14,15,16,17
,18,19,20,21,22,23
....4 LDLTST-C193TGKT
Liquid-emitting Diode Green SMD 0603 angle 130°
2 LED5,6
....4 RS003310F03 REISTORS 33 1% SMD 0603 9 R16,19,21,34,37,40,47,49,50
....4 RS010K10F03 RESISTOR 10K 1% SMD 0603 22
R1,2,3,4,5,6,7,8,26,27,28,29,30,31,32,33,
51,52,53,54,55,56
....4 RS01K210F03 RESISTOR 1.2K 1% SMD 0603 11 R9,10,11,13,14,15,43,44,45,46,48
....4 RS033010F03 RESISTOR 330 1% SMD 0603 12 R17,18,20,22,23,24,25,35,36,38,41,42
....4 RS04R704F06 RESISTOR 4.7 1% SMD 1206 1 R58
....4 RS49R910F03 RESISTOR 49.9 1% SMD 0603 3 R12,39,57
....4 SWEVQ11L05R Switch Tact 5mm 160g Horizonta DIP 10 SW13,14,15,16,17,18,19,20,21,22
....4 UH160808T-600Y BEAD 60 @100MHz 3A ±25% 0603 5 L1,2,3,4,5
...3 TWPC19C020B01T Left PAD PCB SMT Assembly 1 71
....4 AA822524X IC SN74HC165PW 2 IC101,103
....4 CS101J5003NPO CCAP SMD 100pF/50V 5% 0603 NPO 2 C103,108
....4 CS104K5003X7R CCAP SMD 0.1uF/50V 10% 0603 X7R 6 C100,101,105,106,109,112
....4 CS105K1603X7R CCAP SMD 1uF/16V 10% 0603 X7R 2 C111,113
....4 CS475K1605X5R CCAP SMD 4.7uF/16V 10% 0805 X5R 1 C110
....4 CS561J5003NPO CCAP SMD 560pF/50V 5% 0603 NPO 1 C104
....4 ECS22716D8LE
ECAP LOW ESR 220uF/16V 6.3x7.7mm SMD
2 EC100,101
....4 FCN1T1001001 FCN Down Touch Pitch 1.0mm 90° 10Pin 1 FCN100
....4 IC74AHC1G14DBVR IC 74AHC1G14DBVR 1 IC104
....4 IC74HCT595D IC 74HCT595D 2 IC100,102
....4 ICXC6209F452MR IC XC6209F452MR 1 IC105
....4 LDKPT-1608SURCK Liquid-emitting Diode Red SMD 0603 120° 16
LED100,101,102,103,106,107,108,109,11
0,111,112,113,114,115,116,117
....4 LDLTST-C193TGKT
Liquid-emitting Diode Green SMD 0603 angle 130°
2 LED104,105
....4 RS003310F03 RESISTOR 33 1% SMD 0603 6 R115,118,120,125,136,138
....4 RS010K10F03 RESISTOR 10K 1% SMD 0603 16
R100,101,102,103,104,105,106,107,127,
128,R129,130,131,132,133,134
....4 RS01K210F03 RESISTOR 1.2K 1% SMD 0603 6 R108,109,110,111,113,114
....4 RS033010F03 RESISTOR 330 1% SMD 0603 12
R116,117,119,121,122,123,124,126,135,
137,139,140
....4 RS04R704F06 RESISTOR 4.7 1% SMD 1206 1 R143
....4 RS49R910F03 RESISTOR 49.9 1% SMD 0603 3 R112,141,142
....4 SWEVQ11L05R Switch Tact 5mm 160g Horizonta DIP 4 SW112,113,114,115
....4 UH160808T-600Y BEAD 60 @100MHz 3A ±25% 0603 4 L100,101,102,103
...3 TWPC19C020C01T USB PCB SMT Assembly 1 27
....4 CS101J5003NPO CCAP SMD 100pF/50V 5% 0603 NPO 4 C203,206,207,208
....4 CS102K5003X7R CCAP SMD 1nF/50V 10% 0603 X7R 2 C205,209
....4 CS104K5003X7R CCAP SMD 0.1uF/50V 10% 0603 X7R 2 C200,201

Numark MixTrack Pro FX Specifications

General

Type	DJ Controller
Channels	2
Jog Wheels	2
Software	Serato DJ Lite
Number of Decks	2
EQs	3-Band EQ per channel
Audio Interface	Built-in
Crossfader	Yes
USB Connectivity	USB Type-B
Outputs	RCA stereo output
Headphone Output	1/4" and 1/8"
Mixer	2-channel
Pad Controls	Sampler
Software Compatibility	Serato DJ Lite
Performance Pads	8 per deck
Faders	2 x Volume, 2 x Tempo
