Numark MixTrack Pro FX Service Manual

....4 CS225K1605X7R CCAP SMD 2.2uF/16V 10% 0805 X7R 2 C202,204
....4 DITVSNUP2201SM TRANSISTOR Voltage Suppressol Diode 1 D200
....4 ECS10616B Capacitor Electrolytic 10uF/16V B type SMD 3 EC200,201,202
....4 FCN2T1000501
FCN Dual Touch 180° SMD Pitch=1.0mm 5P
1 FCN200
....4 ICNJM-2114M IC Dual OPA NJM-2114M 1 IC200
....4 RS000110F03 RESISTOR 1 1% SMD 0603 2 R201,203
....4 RS001M10F03 RESISTOR 1M 1% SMD 0603 1 R200
....4 RS002716F02 RESISTOR 27 1% SMD 0402 2 R210,211
....4 RS002K10F03 RESISTOR 2K 1% SMD 0603 3 R204,206,209
....4 RS010010F03 RESISTOR 100 1% SMD 0603 1 R207
....4 RS056010F03 RESISTOR 560 1% SMD 0603 2 R205,208
....4 RS510K10F03 RESISTOR 510K 1% SMD 0603 1 R202
....4 TE6A2000502
Pin Header 90° Pitch 2.0mm Single Row 5Pin SMD
1 (TE200)
...3 TWPC19C020D01T RCA PCB SMT Assembly 1
....4 AL2-51-4403 TRANSISTOR 2N4403 PNP 1 Q302
....4 CS101J5003NPO CCAP SMD 100pF/50V 5% 0603 NPO 5 C302,303,304,305,306
....4 CS105K1603X7R CCAP SMD 1uF/16V 10% 0603 X7R 6 C313,319,320,322,323,325
....4 CS106K1605X5R CCAP SMD 10uF/16V 10% 0805 X5R 5 C309,312,324,333,336
....4 CS220J5003NPO CCAP SMD 22pF/50V 5% 0603 NPO 4 C315,316,328,329
....4 CS225K1603X5R CCAP SMD 2.2uF/16V 10% 0603 X5R 3 C326,330,332
....4 CS331J5003X7R CCAP SMD 330pF/50V 5% 0603 X7R 4 C310,311,334,335
....4 CS471J5003NPO CCAP SMD 470pF/50V 5% 0603 NPO 1 C318
....4 DIEN1N4148WSM F Diode 1N4148 SOD123 SMD 2 D300,301
....4 ECS10616B
Capacitor Electrolytic 10uF/16V B type SMD
1 EC300
....4 ECS22716D8LE
ECAP LOW ESR 220uF/16V 6.3x7.7mm SMD
1 EC301
....4 FCN2T1000402
FCN Dual Touch 180° SMD Pitch=1.0mm 4P
1 FCN301
....4 FCN2T1000501
FCN Dual Touch 180° SMD Pitch=1.0mm 5P
1 FCN300
....4 ICDRV604PWP IC DRV604PWP 1 IC301
....4 ICNJM-2114M IC NJM-2114M 1 IC300
....4 RS000010J03 RESISTOR 0 5% SMD 0603 1 R311
....4 RS000110F03 RESISTOR 1 1% SMD 0603 3 R330,332,335
....4 RS001K10F03 RESISTOR 1K 1% SMD 0603 4 R304,309,315,331
....4 RS010010F03 RESISTOR 100 1% SMD 0603 2 R302,307
....4 RS010K10F03 RESISTOR 10K 1% SMD 0603 9 R300,301,306,308,313,319,327,328,329
....4 RS011K10F03 RESISTOR 11K 1% SMD 0603 4 R320,321,338,339
....4 RS018K10F03 RESISTOR 18K 1% SMD 0603 4 R324,325,333,334
....4 RS022K10F03 RESISTOR 22K 1% SMD 0603 1 R326
....4 RS02K410F03 RESISTOR 2.4K 1% SMD 0603 2 R303,305
....4 RS033K10F03 RESISTOR 33K 1% SMD 0603 4 R322,323,336,337
....4 RS100K10F03 RESISTOR 100K 1% SMD 0603 2 R310,312
....4 TE6A2000502
Pin Header 90° Pitch 2.0mm Single Row 5Pin SMD
1 (TE301)
....4 TE6A2000702
Pin Header 90° Pitch 2.0mm Single Row 7Pin SMD
1 (TE300)
....4 TR2SD2114KSM TRANSISTOR 2SD2114K NPN 4 Q300,301,303,306
...3 TWPC19C020E01T HP PCB SMT Assembly 1
....4 CS101J5005NPO
HF CCAP SMD 100pF/50V 5% 0805 NPO
2 C400,401
....4 FCN2T1000402
FCN Dual Touch 180° SMD Pitch=1.0mm 4P
1 FCN400
....4 RS001K10F03 RESISTOR 1K 1% SMD 0603 2 R402,403
....4 RS003308F05 RESISTOR 33 1% SMD 0805 2 R400,401
....4 TR2SD2114KSM TRANSISTOR 2SD2114K NPN 2 Q400,401
...3 TWPC19C020G01T Right Sensor PCB SMT Assembly 1 75
....4 AA822748X Diode BAV99 1 D602
....4 AL2-51-4401 TRANSISTOR 2N4401 NPN 2 Q600,602
....4 CS104K5003X7R CCAP SMD 0.1uF/50V 10% 0603 X7R 4 C600,601,603,604
....4 DIEN1N4148WSM HF Diode 1N4148 1 D600
....4 DIENMMBD4148SE Diode Single MMBD4148SE 100V 200mA 1 D601
....4 IC74LVC2G17DBV IC 74LVC2G17DBV 1 IC600
....4 ICLM393DR IC OPA LM393DR 1 IC601
....4 RS010K10F03 RESISTOR 10K 1% SMD 0603 5 R601,603,607,608,612
....4 RS033210F03 RESISTOR 332 1% SMD 0603 2 R606,611
....4 RS056010F03 RESISTOR 560 1% SMD 0603 2 R604,609

Numark MixTrack Pro FX Specifications

General

Type	DJ Controller
Channels	2
Jog Wheels	2
Software	Serato DJ Lite
Number of Decks	2
EQs	3-Band EQ per channel
Audio Interface	Built-in
Crossfader	Yes
USB Connectivity	USB Type-B
Outputs	RCA stereo output
Headphone Output	1/4" and 1/8"
Mixer	2-channel
Pad Controls	Sampler
Software Compatibility	Serato DJ Lite
Performance Pads	8 per deck
Faders	2 x Volume, 2 x Tempo
