Numark MixTrack Pro FX Service Manual

....4 RS12K110F03 RESISTOR 12K1 1% SMD 0603 1 R600
....4 RS22K110F03 RESISTOR 22.1K 1% SMD 0603 2 R605,610
....4 RS49K910F03 RESISTOR 49.9K 1% SMD 0603 1 R602
....4 TE6A2000601 Pin Header 90° Pitch 2.0mm Single Row 6 1 (TE600)
....4 TR2SK1828 Moset N-CH 20V MAIN 2-Pin 1 Q601
....4 UHBLM18PG121SN1 Bead 120 ±25% 2A 0603 2 L600,601
...3 TWPC19C020H01T Left Sensor PCB SMT Assembly 1 76
....4 AA822748X Diode BAV99 1 D702
....4 AL2-51-4401 TRANSISTOR 2N4401 NPN 2 Q700,702
....4 CS104K5003X7R CCAP SMD 0.1uF/50V 10% 0603 X7R 4 C700,701,702,704
....4 DIEN1N4148WSM HF Diode 1N4148 SOD123 SMD 1 D700
....4 DIENMMBD4148SE Diode Single MMBD4148SE 100V 2 1 D701
....4 IC74LVC2G17DBV IC 74LVC2G17DBV 1 IC700
....4 ICLM393DR IC OPA LM393DR 1 IC701
....4 RS010K10F03 RESISTOR 10K 1% SMD 0603 5 R701,703,707,708,712
....4 RS033210F03 RESISTOR 332 1% SMD 0603 2 R706,711
....4 RS056010F03 RESISTOR 560 1% SMD 0603 2 R704,709
....4 RS12K110F03 RESISTOR 12K1 1% SMD 0603 1 R700
....4 RS22K110F03 RESISTOR 22.1K 1% SMD 0603 2 R705,710
....4 RS49K910F03 RESISTOR 49.9K 1% SMD 0603 1 R702
....4 TE6A2000601 Pin Header 90° Pitch 2.0mm Single Row 6 1 (TE700)
....4 TR2SK1828 Moset N-CH 20V MAIN 2-Pin 1 Q701
....4 UHBLM18PG121SN1 Bead 120 ±25% 2A 0603 2 L700,701
..2 TWPC19C020A01 Right PAD PCB DIP Assembly 1 73
...3 EC22716TLE
ECAP General Purpose 220UF/16V Low ESR
2 EC1,2
...3 VRR10301701 VARIABLE 10KB 1 VR1
...3 VRS10310013 Potentiometer Rotary Valume 10 1 VR2
..2 TWPC19C020C01 USB PCB DIP Assembly 1 27
...3 JK0SCU201RFNO USB CONNECTOR 1 USB200
...3 JK6631501070 Bah Base W/NUT 6.3f 1 JK200
...3 TE622000302
Pin Header 90° Pitch:2.00mm Single Row 3P DIP
1 (TE201)
..2 TWPC19C020D01 RCA PCB DIP Assembly 1 29
...3 JK4130-07520001 2 Pin RCA Jack 1 JK300
..2 TWPC19C020E01 HP PCB DIP Assembly 1 70
...3 JK-3537 3.5mm Phone Jack 9P 90° DIP Female 1 JK400
...3 JY6317-02-030 Earphone base W/NUT 1 JK401
..2 TWPC19C020F01 MIC VR PCB DIP Assembly 1 74
...3 TE622000302
Pin Header 90° Pitch:2.00mm Single Row 3P DIP
1 (TE500)
...3 VRR50301708 Potentiometer Rotary Volume Shat 50K15A 1 VR500
..2 TWPC19C020G01 Right Sensor PCB DIP Assembly 1 75
...3 DIPH574 Photo Sensor 2 SEN600,601
..2 TWPC19C020H01 Left Sensor PCB DIP Assembly 1 76
...3 DIPH574 Photo Sensor 2 SEN700,701
0.1 TWPC19C03101 Main PCB Assembly 1
..2 TWPC19C03101T Main PCB SMT Integration Assem 1
...3 PC19C031 Main PCB 1
...3 TWPC19C031A01T Main PCB SMT Assembly 1
....4 AA822524X IC SN74HC165PW 3 IC16,18,20
....4 AL2-51-4403 TRANSISTOR 2N4403 PNP 1 Q2
....4 AL2-75-4344 IC CS4344-CZZ 24bit 192KHz Stereo D/A 2 IC9,11
....4 AL2-85-0403 IC TPS60403 1 IC7
....4 CS101J5003NPO CCAP SMD 100pF/50V 5% 0603 NPO 16
C20,21,22,23,25,26,28,29,30,31,42,43,50
,111,116,121
....4 CS103K5003X7R CCAP SMD 0.01uF/50V 10% 0603 X7R 4 C2,15,32,33

Numark MixTrack Pro FX Specifications

General

Type	DJ Controller
Channels	2
Jog Wheels	2
Software	Serato DJ Lite
Number of Decks	2
EQs	3-Band EQ per channel
Audio Interface	Built-in
Crossfader	Yes
USB Connectivity	USB Type-B
Outputs	RCA stereo output
Headphone Output	1/4" and 1/8"
Mixer	2-channel
Pad Controls	Sampler
Software Compatibility	Serato DJ Lite
Performance Pads	8 per deck
Faders	2 x Volume, 2 x Tempo
