Numark NS7 - Page 14

..2 AL2-51-4403 TRANSISTOR 2N4403 PNP
1
Q9
..2 AL4-08-0402 CON USB 4-PIN FEMALE PC-MNT HORIZONTAL
1
J1
..2 AL4-15-0803 HEADER SIL 8-PIN 3.96mm MALE LOCKING
1
(J10)
..2 AL7-01-0046 CRYSTAL 12MHz 49US SMD
1
X1
..2 CS101J5003NPO CCAP SMD 100pF/50V 5% 0603 NPO
8
C4~7,10~13
..2 CS104K5003X7R CCAP SMD 0.1uF/50V 10% 0603 X7R 41
C1,2,8,14~20,22~25,30,34,35,38,40,41,49,52~56,58,60
,64,65,67,68,73,78,79,90~95
..2 CS105K1603X5R CCAP SMD 1uF/16V 10% 0603 X5R
1
C3
..2 CS180J5003NPO CCAP SMD 18pF/50V 5% 0603 NPO
4
C9,27,36,37
..2 CS200J5003NPO CCAP SMD 20pF/50V 5% 0603 NPO
2
C39,42
..2 DISDBAT54SSM DIODE BAT54S 30V 0.2A
2
D3,4
..2 EC10625SM ELECT 10uF/25V (SMD)
9
C57,59,61,63,69,80,81,84,85
..2 EC10625T ELECT 10UF/25V
1
C29
..2 EC10725T ELECT 100uF/25V
1
C21
..2 EC10725TNP ELECT 100UF/25V (NP)
8
C28,31~33,62,83,87,88
..2 EC47525TLE ELECT 4.7uF/25V (Low ESR)
1
C26
..2 EC47550TS ELECT 4.7uF/50V (S)
1
C76
..2 EC47635TLE ELECT 47uF/35V (low ESR)
6
C66,70,77,82,86,89
..2 FCN1T1002601 26P FFC CONNECTOR (SMD)
1
J11
..2 IC74AHCT08D IC 74AHCT08D
1
U7
..2 ICBA033FP IC BA033FP
1
U11
..2 ICISP1583BS IC ISP1583BS
1
U4
..2 ICLM317 IC LM317
1
U12
..2 ICNJM-2114M IC NJM2114M
7
U1~3,5,9,10,14
..2 ICWM8594SEF IC WM8594SEF
1
U13
..2 ICYHFRC128 IC YHFRC128 (ICATMEGA162)
1
U6
...3 ICATMEGA162 IC ATMEGA162
1
-
..2 ICYHFRC129 IC YHFRC129(ICLC4032V)
1
U8
...3 ICLC4032V IC LC4032V
1
-
..2 JKLX-1601H-3 XLR BASE 90°
2
J3,4
..2 MC22150T M.CAP 220PF/50V
6
C43,46,47,51,72,74
..2 MC22250T M.CAP 0.0022UF/50V
6
C44,45,48,50,71,75
..2 MT1101810 ground contact slice
1
(J2)
..2 MT1301803 XLRTHED METAL PLATE
2
(J3,4)
..2 PC07C046 MAIN PCB
1
-
..2 RJ1107-09G JACK
1
J2
..2 RS000010J03 RESISTOR 0 5% SMD 0603
2
R61,84
..2 RS001004J06 RESISTOR 10 5% SMD 1206
1
R78
..2 RS001K10F03 RESISTOR 1K 1% SMD 0603
18
R4~11,16,17,20,21,27~30,86,87
..2 RS001M10F03 RESISTOR 1M 1% SMD 0603
2
R2,56
..2 RS004710F03 RESISTOR 47 1% SMD 0603
8
R12,22,44,46,49,62,72,75
..2 RS010K10F03 RESISTOR 10K 1% SMD 0603
1
R40
..2 RS012K10F03 RESISTOR 12K 1% SMD 0603
1
R13
..2 RS01K110F03 RESISTOR 1.1K 1% SMD 0603
4
R73,74,88,89
..2 RS01K510F03 RESISTOR 1.5K 1% SMD 0603
2
R14,68
..2 RS024310F03 RESISTOR 243 1% SMD 0603
1
R71
..2 RS047010F03 RESISTOR 470 1% SMD 0603
3
R55,79,82
..2 RS047K10F03 RESISTOR 47K 1% SMD 0603
2
R43,48
..2 RS100K10F03 RESISTOR 100K 1% SMD 0603
1
R1
..2 RS2K2110F03 RESISTOR 2.21K 1% SMD 0603
12
R18,19,31,32,37,38,41,42,50~53
..2 RS3K7410F03 RESISTOR 3.74K 1% SMD 0603
10
R23~26,63~66,80,81
..2 RS7K1510F03 RESISTOR 7.15K 1% SMD 0603
10
R33~36,57~60,76,77
..2 TE10200601 6P CONNECTOR
1
(J9)
..2 TE10200702 7P CONNECTOR
1
(J7)
..2 TE512540801 TERMINAL 8P 2.54mm
1
(J6)
..2 TE562540601 TERMINAL 6P 2.54MM
1
(J5)
..2 UHACM2012900-2P CHOKE 90 0.4A 2.0X1.2mm
1
L1
..2 XTM11289X3 CRYSTAL 11.2896MHz 49US DIP
1
X3
..2 XTM16000X6 CRYSTAL 16MHz 49US SMD
1
X2
0.1 TWPC07C04701 MIX PCB ASS'Y
1
..2 PC07C047 MIX PCB
1
..2 TWPC07C047A01 MIXER PCB ASS'Y
1 50
...3 AA821786X CRYSTAL 11.2896MHz SO7050 SMD
1
X701
