...3 AL0-17-0103 RESISTOR ARRAY 4X10K 1/10W 0603
3
RA722,724,725
...3 AL0-17-0272 RESISTOR
5
RA731~735
...3 AL0-17-0331 RESISTOR ARRAY 4X3301/10W 0603
3
RA714~716
...3 AL0-17-0470 RESISTOR ARRAY 4X47 1/10W 0603 19
RA701,703~706,708,709,711,712,720,721,723,726~73
0,736,737
...3 AL2-51-4401 TRANSISTOR 2N4401 NPN
2
Q701,702
...3 AL2-51-4403 TRANSISTOR 2N4403 PNP
2
Q703,704
...3 AL2-54-0138 MOSFET BSS138 N-CH SOT-23
1
Q705
...3 AL2-72-0339 IC LM339 ANALOG COMP SOP-14
2
U712,713
...3 AL2-73-4051 IC74HC4051 SINGLE 8-CHAN MUX 16P SOIC
2
U710,711
...3 AL7-20-0075 INDUCTANCE 2.2UH (SMD)
1
L701
...3 CS102J5003NPO CCAP SMD 1nF/50V 5% 0603 NPO
2
C739,740
...3 CS103K5003X7R CCAP SMD 0.01uF/50V 10% 0603 X7R
4
C720,721,734,742
...3 CS104K5003X7R CCAP SMD 0.1uF/50V 10% 0603 X7R 52
C710~719,722,723,726,728~731,733,741,743,744,747
~749,752~757,759,762~767,771~777,779~786
...3 CS152J5005NPO CCAP SMD 1.5nF/50V 5% 0805 NPO
1
C768
...3 CS220J5003NPO CCAP SMD 22pF/50V 5% 0603 NPO
2
C735,736
...3 EC22616TS ELECT 22uF/16V (S)
9
C701~704,706~708,745,770
...3 EC47550TS ELECT 4.7uF/50V (S)
5
C705,709,725,727,732
...3 EC47625TS ELECT 47uF/25V (S)
3
C746,758,778
...3 FCN1T1002602 26P FCC CONNECTOR
6
J701~706
...3 FCN2R1251601 16P FFC CONNECTOR
2
J709,710
...3 IC74ACT574PW IC 74ACT574PW
2
U702,703
...3 IC74AHC245PW IC SN74AHC245PWR
1
U706
...3 ICBA033FP IC BA033FP
1
U707
...3 ICCD4052BM IC CD4052BM
2
U708,709
...3 ICYHFRC130 IC YHFRC130 (AL2-80-0256)
1
U701
....4 AL2-80-0256 IC LCMX0256 TQFP-100
1
-
...3 ICYHFRC131 IC YHFRC131 (AL2-70-3433)
1
U705
....4 AL2-70-3433 IC UPSD3433EV-40U6
1
-
...3 LD-005HLV RED LED
16
LED712~714,718~730
...3 LDYH-11R5W1R5 LED BAR
1
(LED701-711)
...3 MT070446701 IRON PLATE
1
(E701)
...3 MT1104473 FIXED PLATE
2
(P705)
...3 PT111048005 FIXED BASE,LED
16
(LED712~714,718~730)
...3 RS000010J03 RESISTOR 0 5% SMD 0603
5
C737,738,769,R708,709
...3 RS001004J06 RESISTOR 10 5% SMD 1206
1
R729
...3 RS001M10F03 RESISTOR 1M 1% SMD 0603
2
R730,731
...3 RS002210F03 RESISTOR 22 1% SMD 0603
2
R705,706
...3 RS004710F03 RESISTOR 47 1% SMD 0603
3
R732,RA702,740
...3 RS010K10F03 RESISTOR 10K 1% SMD 0603
7
R701,702,713,718,723,727,728
...3 RS01K510F03 RESISTOR 1.5K 1% SMD 0603
10
R703,738~746
...3 RS01K810F03 RESISTOR 1.8K 1% SMD 0603
1
R712
...3 RS022010F03 RESISTOR 220 1% SMD 0603
9
R726,733,734,747~752
...3 RS024304F06 RESISTOR 243 1% SMD 1206
1
R719
...3 RS047010F03 RESISTOR 470 1% SMD 0603
8
R710,711,735~737,753~755
...3 RS100K10F03 RESISTOR 100K 1% SMD 0603
5
R707,714~717
...3 RS22K110F03 RESISTOR 22.1K 1% SMD 0603
1
R720
...3 RSN0000104J03 SMD RESISTOR 0R
2
RA710,739
...3 SC2606RINI SCREW
2
(P705)
...3 SWDC11B2021431 SWITCH
1
E701
...3 SWEVQ11L05R Switch Tact Stem Height 5mm Operating
8
S701~708
...3 SWSSFUB22-10K Switch Slide Single Row 180°
1
S709
...3 TE10200601 6P CONNECTOR
4
(J712,716~718)
...3 TE512540801 TERMINAL 8P 2.54mm
1
(J714)
...3 TE612000301 3P CONNECTOR
3
(J707,708,720)
...3 TE622000801 8P CONNECTOR
1
(J711)
...3 TE962541401 CONNECTOR 14P
1
(J715)
...3 VRR10301701 VARIABLE 10KB
4
P704,709~711
...3 VRR10301704 Poltertiomaeter Rotary Volume 10K2B
6
P701~703,706~708
...3 VRS10303006 Potentiometer Slide 10k 15mm
1
P705
...3 XTM40000X4 CRYSTAL 40MHz 49US DIP Fundamental
1
X702
..2 TWPC07C047B01 LEFT TRANSPORT PCB ASS'Y
1 49
