Numark NS7 - Page 16

...3 AL0-17-0221 RES ARRAY 4X220 1/10W 0603
6
RA400,402,404,406,407,421
...3 AL0-17-0272 RESISTOR
9
RA412~420
...3 AL0-17-0331 RES ARRAY 4X3301/10W 0603
2
RA401,405
...3 AL1-16-0472 ELECT
1
C409
...3 CS104K5003X7R CCAP SMD 0.1uF/50V 10% 0603 X7R
14
C400~403,407,408,410~413,415,416,419,426
...3 EC22616TS ELECT 22uF/16V (S)
3
C404~406
...3 FCN1S1000401 4P FFC CONNECTOR
1
J403
...3 FCN1T1002602 26P FFC CONNECTOR
2
J400,401
...3 IC74ACT574PW IC 74ACT574PW
4
U400~403
...3 IC74AHCT245PW IC SN74AHCT245PWR
4
U404~407
...3 LD-005HLV RED LED 34
LED401,403,405,407,409,411,413,415,417,419~421,4
24~426,428,430~437,442~444,446,448~452,454
...3 LD304W2CB Liguid-Emitting Diode White Astigmatism 15
LED400,402,404,406,408,410,412,414,416,418,422,42
3,427,429,447
...3 NM3506103 VELET CARPET
1
(P400)
...3 PT111048005 FIXED BASE,LED
49
(LED400~437,442~444,446~452,454)
...3 RS000010J03 RESISTOR 0 5% SMD 0603
1
C433
...3 RS001K10F03 RESISTOR 1K 1% SMD 0603
3
R432~434
...3 RS004710F03 RESISTOR 47 1% SMD 0603
1
R416
...3 RS010K10F03 RESISTOR 10K 1% SMD 0603
8
R407~414
...3 RS01K510F03 RESISTOR 1.5K 1% SMD 0603
4
R425,426,435,437
...3 RS022010F03 RESISTOR 220 1% SMD 0603
5
R402,405,424,431,445
...3 RS033010F03 RESISTOR 330 1% SMD 0603
4
R401,403,406,436
...3 RS047010F03 RESISTOR 470 1% SMD 0603 14
R400,417~421,423,438,439,442,444,446,448,450
...3 RS100K10F03 RESISTOR 100K 1% SMD 0603
1
R404
...3 SWEVQ11L05R Switch Tact Stem Height 5mm Operating
27
S401~413,418~431
...3 TE612000301 3P CONNECTOR
1
(J402)
...3 TE962540801 Female Meader 180° Pitch 2.54mm 4PinX2
1
(J404)
...3 VRR10301301 Potentiometer Rotary 10k Shaft Length 13
2
P402,405
...3 VRS10310013 Potentiometer Rotary Valume 10KB Shaft
1
P400
..2 TWPC07C047C01 PHONE PCB ASS'Y
1 44
...3 CS104K5003X7R CCAP SMD 0.1uF/50V 10% 0603 X7R
6
C101,102,105,109,114,115
...3 CS331J5005NPO CCAP SMD 330pF/50V 5% 0805 NPO
2
C112,113
...3 ICNJM-2114M IC NJM2114M
2
U100,101
...3 JK-3537 BAHF BASE 3.5
1
J102
...3 JKLJB0661H-6-A JACK 1/4 STEREO 6PIN
1
J103
...3 R33012T RESISTOR 33 5% 1/2W DIP
8
R108~111,114~117
...3 RS047K08F05 RESISTOR 47K 1% SMD 0805
2
R100,101
...3 TE10200601 6P CONNECTOR
3
(J100,406,407)
...3 TE10200702 7P CONNECTOR
1
(J101)
...3 VRR10301502 VARIABLE RESISTANCE
1
P100
..2 TWPC07C047D01 Bleep/Reverse PCB ASS'Y
1 46
...3 SWLBCR23M-095 SWITCH
1
S400
...3 TE562540803 Pin Header 180° Pitch 2.54mm Dual Row
1
(J405)
0.1 TWPC07C04801 FUNCTION PCB ASS'Y
1
..2 PC07C048 FUNCTION PCB (366X290mm)
1
..2 TWPC07C048A01 RIGHT TRANSPORT PCB ASS'Y
1 51
...3 AL0-17-0221 RES ARRAY 4X220 1/10W 0603
6
RA500,502,504,506,507,521
...3 AL0-17-0272 RESISTOR
9
RA512~520
...3 AL0-17-0331 RES ARRAY 4X3301/10W 0603
2
RA501,505
...3 AL1-16-0472 ELECT
1
C509
...3 CS104K5003X7R CCAP SMD 0.1uF/50V 10% 0603 X7R 14
C500~503,507,508,510~513,515,516,519,526
...3 EC22616TS Capacitor Electrolytic 22uF/16V 5*5mm
3
C504~506
...3 FCN1S1000401 4P FFC CONNECTOR
1
J503
...3 FCN1T1002602 26P FFC CONNECTOR
2
J500,501
...3 IC74ACT574PW IC 74ACT574PW
4
U500~503
...3 IC74AHCT245PW IC SN74AHCT245PWR
4
U504~507
...3 LD-005HLV RED LED 34
LED501,503,505,507,509,511,513,515,517,519~521,5
24~526,528,530~537,542~544,546,548~552,554
