Numark NS7 - Page 18

...3 VRR50201503 Potentiometer Rotary Volume 5K2BX2 shaft
2
VR201,202
2
TWPC07C048E01 POWER PCB ASS'Y
1
74
3 AL2-51-0140 DIODE MBRS140LT3
3
D601~603
3 AL2-51-4401 TRANSISTOR NPN 2N4401
1
Q600
3 AL2-56-0753 TRANSISTOR PNP FZT753
1
Q602
3 AL2-61-3463 IC REG VOLTAGE MC34063A ADJ 10
1
U602
3 AL4-15-0803 HEADER SIL 8-PIN 3.96mm MALE L
1
(J603)
3 CS104K5003X7R CERAMIC 0.1UF (SMD) 13
C601,603,605,607,608,611,613,616,618,619,623,628,6
29
3 CS105K1603X7R CERAMIC 1UF (SMD)
1
C615
3 CS201J5003NPO CERAMIC 200P (SMD)
1
C622
3 DISDMBRD835LT4G DIODE
1
D600
3 EC22735TLE ELECT 220UF/35V 15
C600,602,604,606,609,610,612,614,617,620,621,624,6
26,627,634
3 IC7810 IC 7810
1
U603
3 ICAP1501K5L IC AP1501K5L
2
U600,601
3 NUT0103INI NUT 3M/M
1
(U603)
3 R15001 RESISTOR Carbon Film 15 5% 1W DIP
1
R614
3 RS000004J06 RESISTOR 0 (SMD) 1206
2
R615,616
3 RS001K10F03 RESISTOR 14K (SMD)
1
R604
3 RS010K10F03 RESISTOR 820 (SMD) 1206
2
R602,607
3 RS014K10F03 RESISTOR 0.2 (SMD) 2512
2
R606,611
3 RS022K10F03 RESISTOR 1K (SMD)
1
R601
3 RS056010F03 RESISTOR 10K (SMD)
1
R613
3 RS082004F06 RESISTOR 1.05K (SMD)
1
R612
3 RS0R2001F12 RESISTOR 22K (SMD)
1
R609
3 RS1K0510F03 RESISTOR 3.24K (SMD)
3
R605,608,610
3 RS3K2410F03 RESISTOR 560 (SMD)
1
R600
3 SC0308RIBI SCREW
1
(U603)
3 TE612000202 2P CONNECTOR
2
(J604,605)
3 TE613960201 2P CONNECTOR
2
(J601,602)
3 TE613960602 6P CONNECTOR
1
(J600)
3 UH465516-351 COMMON MODE CHOKE
1
L603
3 UHLFTBH1204-121 COMMON MODE CHOKE,120UH,3A
2
L600,601
3 UHPID1207-331M CHOKE COILS 330uH 0.95A SMD
1
L605
3 UHPID1207-680M CHOKE COILS 68uH±20% 3A SMD
1
L602
3 UHPIH6D28-220M CHOKE COILS 22uH 1.2A SMD
1
L608
3 UHSMTDRRI125-101M INDUCTANCE (100UH/1.3A)
1
L604
..2 TWPC07C048F01 Bleep/Reverse PCB ASS'Y
1 52
...3 SWLBCR23M-095 SWITCH
1
S500
...3 TE562540803 Pin Header 180° Pitch 2.54mm Dual Row
1
(J505)
..2 TWPC07C048G01 Shielding PCB ASS'Y
1 102
..2 TWPC07C048H01 Shielding PCB ASS'Y
1
..2 TWPC07C048I01 SWITCH POWER HOLDER PCB ASS'Y
1 127
0.1 TWPC07C04901 CROSS FADER PCB ASS'Y
1 70
..2 PC07C049 CROSS FAFER PCB
1
-
..2 TE10200602 6P CONNECTOR
1
(J2)
..2 VRS50304513 VARIABLE RESISTANCE
1
P2
0.1 TWPC08P00101 MOTOR CONTROL PCB ASS'Y
2 39
..2 CC104100Z C.CAP 0.1UF/100V
1
C39
..2 CS102K5005X7R CCAP SMD 1nF/50V 10% 0805 X7R
3
C9,41,42
..2 CS103K5005X7R CCAP SMD 0.01uF/50V 10% 0805 X7R
1
C54
..2 CS104Z5005Y5V CCAP SMD 0.1uF/50V +80/-20% 0805 Y5V
26
C1,2,7,8,14,16~26,32~35,37,44,48,57~59
..2 CS200J5005NPO CCAP SMD 20pF/50V 5% 0805 NPO
2
C5,6
..2 CS334K1605X7R CCAP SMD 0.33uF/16V 10% 0805 X7R
1
C3
..2 CS682K5005X7R CCAP SMD 6.8 nF/50V 10% 0805 X7R
1
C4
