Numark NS7 - Page 19

..2 DIN5406 DIODE DIN5406
1
D3
..2 DISR26 SCHOTTKY BARRIER RECTIFIER
1
D01
..2 DIZDP6SMB47CAT3 DIODE TVS (47V)
2
ZD01,02
..2 EC10616T ELECT 10UF/16V
2
C12,15
..2 EC10716T ELECT 100uF/16V 5*11mm
1
C36
..2 EC10850 ELECT1000uF/50V
1
C38
..2 EC33725TLE ELECT 330uF/25V (low ESR)
1
C30
..2 EC33750T ELECT 330uF/50V
1
C11
..2 EC47550T ELECT 4.7uF/50
3
C27,28,29
..2 EC47616T ELECT 47uF/16V
1
C13
..2 FCN2S1251601 16P FFC CONNECTOR
1
CON02
..2 IC74AHC245PW IC SN74AHC245PWR
1
U2
..2 ICAP1501K5L IC AP1501K5L
1
IC2
..2 ICAPL1117-33V IC APL1117-33V
1
IC3
..2 ICBA4558F IC BA4558F
1
IC8
..2 ICMIC809 IC MIC809
1
IC4
..2 ICOPA354 IC OPA354
1
IC1
..2 ICYH08P01 IC YH08P01
1
IC5
...3 ICTMS320LF2407A IC TMS320LF2407A
1
-
..2 MOF01003 M.RES 1 3W
1
R47
..2 MT0703321 FIXED PLATE
2
-
..2 NP211MAR79 NAME PLATE
1
-
..2 PC08P001 MOTOR CONTROL PCB 2LAYER FR-4 1.6T
1
-
..2 R10112 RESISTOR
3
R20,29,38
..2 RS000004J06 RESISTOR 0 5% SMD 1206
1
R11
..2 RS001608F05 RESISTOR 16 1% SMD 0805
1
R8
..2 RS001K08F05 RESISTOR 1K 1% SMD 0805 18
R14,17,19,24,28,32,37,46,51,55,59,63,68~70,75,115,1
18
..2 RS001M08F05 RESISTOR 1M 1% SMD 0805
1
R21
..2 RS010K08F05 RESISTOR 10K 1% SMD 0805 30
R1,2,3,4,5,6,7,9,10,12,16,22,26,30,31,35,40,44,48,53,5
6,61,94,95,96,97,98,110,112,116
..2 RS02K208F05 RESISTOR 2.2K 1% SMD 0805
2
R93,114
..2 RS033K08F05 RESISTOR 33K 1% SMD 0805
4
R78,79,86,91
..2 RS03K308F05 RESISTOR 3.3K 1% SMD 0805
1
R117
..2 RS03K908F05 RESISTOR 3K9 1% SMD 0805
6
R13,23,33,42,50,58
..2 RS04K708F05 RESISTOR 4.7K 1% SMD 0805
6
R15,25,34,43,52,60
..2 RS06K808F05 RESISTOR 6.8K 1% SMD 0805
7
R18,27,36,45,54,62,111
..2 RS100K08F05 RESISTOR 100K 1% SMD 0805
1
R113
..2 RS1K0508F05 RESISTOR 1.05K 1% SMD 0805
1
R65
..2 RS3K2408F05 RESISTOR 3.24K 1% SMD 0805
1
R64
..2 SC0308RBNI SCREW M3*8MM PRN TAPPING
6
-
..2 SC3508RBNI SCREW
4
-
..2 TE613960201 2P CONNECTOR
1
CON7
..2 TE962541401 CONNECTOR 14P
1
CON1
..2 TE962542401 CONNECTOR 24P 2.54MM
1
CON3
..2 TR2SA1037ASM TRANSISTOR 2SA1037AK PNP SOT-23
1
Q43
..2 TR2SB1340-T-B TRANSISTOR 2SB1340 PNP TO-220
3
Q6,11,16
..2 TR2SC2412KSM TRANSISTOR 2SC2412K NPN SOT-23
1
Q39
..2 TR2SD1889 TRANSISTOR 2SD1889 NPN TO-220
3
Q23,28,33
..2 TRIRLML5103 MOSFET IRLML5103 P-CH SOT-23
6
Q4,9,14,21,26,31
..2 TRRK7002 MOSFET RK7002 N-CH SOT-23 18
Q2,3,5,7,8,10,12,13,15,19,20,22,24,25,27,29,30,32
..2 UH322522T-100K CHOKE COIL 100UH
2
L1,2
..2 UH453232T-3R3K CAPACITOR
2
L4,5
..2 UHPID1207-680M Inductor 68uH±20% 3A SMD
1
L3
..2 XTM08000X6F1 CRYSTAL 8MHz 49US SMD Fundamental
1
Y2
1 MD-969YH01 DD MOTOR 2
2
TWPC08P00301 MOTOR PCB ASS'Y
1
2 PC08P003 MOTOR PCB SINGLE LAYER FR1(146
1
3 TWPC08P003A01 MOTOR PCB ASS'Y
1
4
CS104Z5005Y5V CEAMIC 0.1UF (SMD)
5
C48,49,81,82,83
4
HSEW510 HALL SENSOR IC EW510
3
HS100,101,102
4
JW5206T JUMP WIRE
4
J1,2,3,4
