4
RS000008J05 RESISTOR 0 (SMD)
7
R84,85,86,87,88,89,90
4
RS010K08F05 RESISTOR 10K (SMD)
3
R81,82,83
4
TE612000402 4P CONNECTOR
1
CON8
4
TE612000403 4P CONNECTOR
1
CON9
4
TE962542401 24P CONNECTOR
1
TE01
3 TWPC08P003B01 OPTICAL ENCODER PCB ASS'Y
1
4
CN0420000704 4P CONNECTOR (70mm)
1
CON10
4
CS104Z5005Y5V CERAMIC 0.1UF (SMD)
1
C51
4
DIHEDS-9700F50 SENSOR
1
PH1
4
JW5206T JUMP WIRE
1
J5
3 TWPC08P003C01 OPTICAL ENCODER PCB ASS'Y
1
4
CN0420001302 4P CONNECTOR (130mm)
1
CON11
4
CS104Z5005Y5V CERAMIC 0.1UF (SMD)
1
C52
4
DIHEDS-9700F50 SENSOR
1
PH2
4
JW5206T JUMP WIRE
1
J6
