Numark X5 Service Manual

2. REMOVING OF THE BOTTOM CHASSIS (Fig2).
(A) REMOVE 12 SCREWS BEFORE REMOVING OF THE BOTTOM CHASSIS.
(Fig.2)
3. REMOVING OF THE REAR PANEL AND DISASSEMBLE THE I/O PCB
ASSEMBLY. (Fig3).
(A) REMOVE 13 SCREWS.
(B) REMOVE 2 NUTS TO DISSEMBLING THE REAR PANEL AND THE I/O PCB ASSEMBLY.
(Fig.3)

Numark X5 Specifications

General

Brand	Numark
Model	X5
Category	Music Mixer
Language	English
