Numatic HGB 817 - Control Panel Overview

1
Battery Charge Level Indicator
2
Vacuum Pick Up On / O
3
Water Flow On / O
4
Hours Meter
5
Handle Position Lever
6
Triggers
7
Charging Point
8 On / O Switch
Control Panel Overview
In the event of a breakdown contact
your N
aceCare dealer or the
NaceCareTechnical
help line 905-795-0122
SCRUBBER DRYER
HGB
817/3045 / TGB 817/3045 / TGB 4045 /
TGB 4055
1
5
2
3
6
6
7
8
4
