12
Safety Critical Component
Mains Lead: H05VV-F x 1.5mm
2
x 3 core
Brush Motor Vac Motor Power Sound Pressure Speed Brush Pad
1500W 1200W 220-240v 50Hz
220v 60Hz
120v 60Hz
110v 50Hz
80 dB(A) 50Hz = 150rpm
60Hz = 180rpm
635mm 600mm
Gross Weight Full Protection Class Hand Arm Vibration Dimensions Net Weight Cleaning Range Water Capacity
147.6Kg Class 1 1.3+/- 0.05ms² 1230x1260x970 87.6 Kg 42m 60 L
About the Machine
WEEE (Waste, Electrical and Electronic Equipment)
Scrubber dryer Accessories and packaging should be sorted for environmentally-friendly recycling.
Only for EU countries.
Do not dispose of scrubber-dryer into household waste.
According to the European Directive 2002/96/EC on waste electrical electronic equipment and its
incorporation into national law.
Scrubber-dryers that are no longer suitable for use must be separated, collected and sent for
recovery in an environmentally-friendly manner.
1
2
3
4
5
6
7
8
9
In the event of a breakdown contact your Numatic dealer or the
Numatic Technical help line +44 (0)1460 269268
10
Rating Label
1
2
3
4
5
6
7
8
9
Company Name & Address
Machine Description
Voltage Frequency
Power Rating
WEEE Logo
Ingress Protection Rating
Max Gradient
CE Mark
Weight (ready to use)
Machine year/week Serial number
Machine Description
Noise Rating
Hand Arm Vibration
10
12
11
13
11
12
13
Ear Protection Safety Footwear Head Protection Safety Gloves
Dust/Allergens
Protection
Eye Protection Protective
Clothing
Hi-Vis Jacket
Caution
Wet Floor Sign
Note:
A risk assessment should be conducted to determine which PPE should be worn.
PPE (Personal protective equipment) that may be required for certain operations.
