Child Restraint Overview
Seat Assembly
1
- With the seat lying flat, attach the Seat Back to
the booster Seat Bottom by hooking the Seat Back
hooks over the Seat Bottom as shown.
2 - Now rotate the Seat Back up until it clicks into
position and the seat is fully upright as shown.
Side Impact Protection (SIP) Pods
3
- To open the SIP Pods pull out on the side tab.
4 - To close push button (1) and push in (2.
SIP Pods should be deployed whenever the Child
Restraint is installed in a vehicle.
Seat Adjustment for Head
Support and Shoulders
The Head Support height can be adjusted for best
fit to your child and proper placement of the Vehicle
Shoulder Belt. Before adjusting the Head Support
height have your child lean forward slightly.
Bottom of Head Support MUST be even with the
top of your child’s shoulder.
5 - To adjust, squeeze the Head Support Adjustment
Lever, then pull up or push down the Head Support
until it locks into one of the nine positions.
As the Head Support is adjusted up, the sides of the
seat automatically move outward to provide more
shoulder room.
click
click
click
1
2
