Securing a Child in the High
Back Booster Mode
1
- With the booster correctly positioned in the
vehicle, raise the Head Support and route the
Vehicle Shoulder Belt through the RED shoulder
belt guide (1). The bottom of the Head Support
should be at the top of the child’s shoulder. Route
the Vehicle Shoulder Belt across the child’s chest
through the RED lower belt path, located under
the armrest, toward the vehicle buckle (2). Then
secure the vehicle buckle and listen for a “click.”
The vehicle lap belt must lie flat and snug across
the child’s thighs. The Vehicle Lap Belt must be
positioned low on the pelvis (3).
DO NOT position the Vehicle Lap Belt over the
armrest. It must pass under the armrest.
Make sure the Vehicle Shoulder Belt is routed
completely through the shoulder belt guide.
2 - To properly adjust the Head Support, have your
child sit in the booster with their back flat against
the back of the booster seat. The correct Head
Support height is obtained when the bottom of the
Head Support is even with the top of your child’s
shoulders and the Vehicle Shoulder Belt is laying flat
across their chest. Pull up towards the vehicle belt
retractor to remove slack.
3 - The Vehicle Shoulder Belt must route completely
through the RED Shoulder Belt Guide and not fall
off the child’s shoulder.
1
3
2
click
