INSTALLATION
INSTALLATION
Checklist - ISOFIX Installation
1
Fit guide onto
steel rod
2
ISOFIX Compatible Connector Guides
1 Some models come with
guides for the ISOFIX
compatible connectors.
These are for use in cars
where the anchorage bar
is recessed a long way
into the seats.
Once tted they will
help guide the ISOFIX
compatible connector
into place.
2 To use:
• locate the position of
the ISOFIX low anchor-
age,
• slide the guide in until
it contacts the steel rod
• allow the guide to push
up until it is secure on the
steel rod.
1 Check the bubble
level indicator to see
if recline level is still
correct.
Adjust if necessary.
2. Pull back to check
both sides are latched
securely.
2
2
1
