INSTALLATION
INSTALLATION
Do not adjust so tight that
it lifts the child restraint off
the vehicle seat.
Store unused web in bag on
end of tether.
Tether Strap - Use
Straps must
not be twisted
Most cars have several
threaded holes to t the
tether anchorage to.
Refer to the vehicle owners
handbook for information
on the location of these
points.
Using the bolt provided
attach the anchor tting to
the mounting point behind
where the child restraint is
to be installed.
See more detailed
information on the next
page.
The threaded hole for
the anchorage bolt
may have a plastic
cover over it
centre-line of seating position
100 mm
minimum
The anchor tting must be
aligned as shown unless
stated otherwise in the
vehicle owners handbook.
If drilling a new hole, select
a position on the centre line
of the seating position, and
no closer than 100 mm from
the front edge of the parcel
shelf.
Tether Anchorage - Installation
To Next Page
