INSTALLATION
INSTALLATION
INSTRUCTIONS
3
2
Features
1
4
10
8
7
1 Tether Strap
2 Child Restraint Release
Lever
3 Tether Strap Anchorage
4 Tether end storage
5 Vehicle Belt Lock-Off
6 Bubble Level Indicator
7 Instruction Manual
Storage
8 Recline Foot
9 ISOFIX connector
10 Recline Foot Fold Latch
11 ISOFIX connectors fold
latch
6
11
9 9
9
5
Where to install the child
restraint?
Only install the child re-
straint in a forward facing
vehicle seat.
Never install in a seat that
faces the rear or the side of
the vehicle.
Install in the rear seat, the
safest place is normally the
centre.
The base can be installed
on vehicles seats tted with
either a lap belt or a lap/
sash belt or ISOFIX anchor-
ages.
To install correctly the
vehicle must be on a level
surface.
IMPORTANT:
Correct position and
installation is essential
for your child's safety.
Installation - General
