INSTALLATION
INSTALLATION
1
1 Position base on a
forward facing vehicle
seat.
Adjust base so bubble
is between the black
patches.
2 Use recline adjustment,
if needed, to achieve
correct angle for
installation.
Recline adjustment foot
snaps into position.
3 If the recline adjustment
foot does not give
sufcient recline, add a
folded towel or similar.
3
2
IMPORTANT:
Any extra padding
placed under the base
must be firmly folded so
that when the vehicle
belts are pulled up tight,
the base is secure.
Always secure the base
with a vehicle belt, even
when the restraint is not
fitted to it. An unsecured
base may be dangerous
in an accident or sudden
stop.
Installation — Vehicle Belts
REARWARD-FACING
BELT PATH
INSTALLED
BASE
Use the Belt Path
labels as a guide for
correct belt placement.
To Next Page
