Nuna KLIK plus - Vehicle Belt Installation Procedure; Thread Vehicle Belt; Open Belt Lock-off; Buckle Vehicle Belt

1110
INSTALLATION
INSTALLATION
3. Buckle the vehicle belt.
2. Open the belt lockoff
and place the shoulder
and lap belts across it.
4. Push the base into the
vehicle seat rmly A and
pull the vehicle belts
tight B.
5. Hold vehicle belts tight
and engage the belt
lockoff.
"CLICK"
3
4
A
B
2
3. Vehicle belt is not
twisted.
4. Level indicator
bubble is fully in the
clear area.
2. Vehicle belt is tight.
2
Checklist — Vehicle Belt Installation
1. Vehicle Buckle
engaged.
1
5
4
3
BELTS MUST BE
TIGHT.
LOOSE BELTS ARE
DANGEROUS.
1. Place the base on the
vehicle seat and pass
the vehicle belt through
the openings in the base
labeled ‘BELT PATH’
1
Installation — Vehicle Belts
