Nuna pipa lite rx User Manual

16 PIPA lite rx instructions 17PIPA lite rx instructions
PIPA
™
lite rx Parts List
Make sure all parts are available before
assembly. The infant carrier module
and base can be sold separately. If any
part is missing, please contact Nuna
(see page 5 for information). No tools
are required for assembly.
1 Head Support/Harness Height
Adjustment Loop
2 Head Support x2*
3 Seat Pad
4 Shoulder Pads x2 set
5 Chest Clip
6 Body Support x2
7 Low Birth Weight Pillow (inside
back of Body Support)
8 Buckle
9 Harness Adjustment Button
10 Harness Adjustment Strap
11 Crotch Pad x2
12 Belt Guide (Lap Belt)
13 Magnetic Buckle Holder
14 Handle Adjustment Button
15 Stroller Release Button (Side)
16 Handle
17 Canopy Drape Zipper
18 Canopy Window
19 Canopy
20 Stroller Release Button (Rear)
21 Belt Guide (Shoulder Belt)
22 Canopy Mount
23 Base Attachment Bars
24 Shoulder Harness Straps
25 Harness Splitter Plate
22
18
19
20
21
23
24
25
2
1
3
4
5
8
9
11
13
14
15
16
17
12
7
(back)
6
10
*Certain models only

Nuna pipa lite rx Specifications

General

Brand	Nuna
Model	pipa lite rx
Category	Baby Carrier
Language	English
