20
2 Position base in a forward facing
vehicle seat. Use recline adjustment
to position bubble in indicator.
Adjust base so bubble touches line.
3 Use recline adjustment, if needed, to
achieve correct angle for installation
4 Recline adjustment snaps
into position
5 For instructions on using the stability
leg when installing the base, see stability leg section.
(Page 22)
6 Route the vehicle belt through the opening in the base
labeled ‘Belt Path’ and buckle the vehicle belt. Both the
shoulder AND lap belt must be under the blue lock off.
1
3
2
