Nuna Pipa User Manual

25
8 Check the installation.
a) Blue line must be level with ground.
b) Vehicle belt must be buckled, tight and locked.
c) Carrier must be stable – Carrier should not move side to
side more than 1 inch at belt path.
Locking Clip Use
a) Tighten the buckled belt by pushing down hard on the
infant restraint and pulling hard on the shoulder belt.
b) While pushing down on infant restraint, pinch the two
straps together behind the buckle tongue. Unbuckle the
belt without allowing it to slip.
c) Connect lap and shoulder belts with locking clip.
d) Rebuckle belt. Check that lap belt does not move by
pulling and pushing hard on infant restraint. If belt
loosens or lengthens, repeat procedure.
The locking clip should
be 1/2 inch (12.5mm)
from the buckle.
1/2 inch
(12.5mm)

Nuna Pipa Specifications

General

Product color	Red
Car seat group	0+ (0 - 13 kg; 0 - 15 months)
Side protection	Yes

Weight and Dimensions

Depth	700 mm
Width	435 mm
Height	530 mm
Weight	3950 g
