REBL basq Instructions
REBL basq Instructions
EN
EN
The load leg must be installed correctly with
green indicator. (13)-2
Height Adjustment
for Head Support and Shoulder Harnesses
Check that Shoulder Harness Straps are set at the
proper height.
Shoulder Harness Straps must be at a height nearest
to your childs shoulders (14), but not above the
shoulder line. (15)
If the Shoulder Harness Straps are not at the proper
height, the child might be ejected the Enhanced Child
Restraint if there is a crash.
Squeeze the head support adjustment lever (16),
while pulling up or down on the head support until it
snaps into one of the 8 positions. The head support
positions are shown as (17).
Securing Child
After the child is placed into the seat, check whether
the Shoulder Harness Straps are at proper height.
1 - While pressing the adjustment button located at
the front of the Enhanced Child Restraint, pull the
two Shoulder Harness Straps of the Enhanced
Child Restraint. (18)
2 - Unlock the buckle of the harnesses by pressing
the red button. (19)
8 - Press the ISOFIX adjustment button to store the
ISOFIX. (9)
The completely assembled Enhanced Child Restraint
is shown as (10).
Recline Adjustment
Squeeze the recline adjustment button (11)-1, to adjust
the Enhanced Child Restraint to the proper position.
The recline angles are shown as (11).
Please recheck the load leg position after reclining.
There are 7 recline angles for baby mode and 7
positions for toddler mode.
Baby Mode (Rearward Facing Mode)
Rearward Facing
Child height 61cm-105cm/Child weight≤18.5kg
Recline position
Position 1-7
1 - Press the rotating button to rotate the seat facing
the rear of the vehicle. (12)(13)
Please recline the seat to be in positions 3
through 7 for ease of rotation.
2 - Rearward facing mode assembled as (13).
The ISOFIX connectors must be attached and
locked onto the ISOFIX anchor points. (13)-1
To Next Page
