Operating instructions for use
EB EASY-PRINTER
Eggland’s Best, Inc. Operating Standards Manual- EB Easy Printer Manual 16/001
Confidential. Do not reproduce without permission December 6, 2016
10
1
2
3
4
6.9 Complete stamping bar
To change, clean or maintain the imprint heads, the entire imprint head bar can be removed from the EB EASY-
PRINTER machine.
To remove the stamping-bar from the EB EASY-PRINTER machine:
1 Move the lower part of the bar in the direction of the arrows (number [1]).
2 Move the complete bar in the direction of the arrows (number [2]).
6.10 Service bracket
The service-tool set to position [3] is used to service/clean or refill the imprint heads. (Optional)
To use the service mounting tool to store printer assemblies, place the printer head bar into the slot as shown
[4].
6.11 Parking station for individual ink reservoirs
The individual ink reservoirs can be parked (Optional) as shown:
