Nupi Elofit Smartflex - Machine Diagram and Components

5
Welding unit characteristics
(Machine diagram)
1. Machine body
2. 4-line LCD display
3. Power switch
4. Button strip with:
to confirm entered data
to delete entered data or return to the previous display
or to scroll up/down menu figures
5. Welding cables
6. Barcode scanner
7. Ambient temperature detecting sensor
8. Cooling fan
