Nupower EVOLUTION NPECH250 - COMPONENTS AND CONTROLS; MOUNTING INSTRUCTIONS; OPERATION; MAINTENANCE

16
GB
COMPONENTS AND CONTROLS (PIC. 1)
1 Electric hoist
2 Control switch
3 Emergency stop button
4 Hook
5 Safety bar
6 Counter weight
7 Up limit bracket for limit stop
8 Steel cable
9 Mounting brackets
10 Down limit bracket for limit stop
MOUNTING INSTRUCTIONS (PIC. 2)
Check the device for damage in transit. Please advise
the delivery company immediately if you discover any
damage.
Mounttheelectric hoistusingthesupplied bracketstoa
structureofsufficientlystrengthtosupport250Kgwithout
failureandthatwillholdthehoistinahorizontalposition.
If alternative brackets are used ensure that they are of
sufficient strength and align with the mounting holes on
thehoist.
OPERATION (PICS. 3 TO 7)
Warning!
Read and understand the instruction manual before using
the electric hoist.
Before lifting a load make sure that the steel cable is
correctlywoundontothecabledrum(Pic.3).Ensurethe
loadtobeliftedisdirectlybelowthehoistandanylifting
chains,straps,slings,ropesandshacklesaresufficiently
strongandcorrectlypositionedtocarrytheweightofthe
loadsafelyandsecurely.
Attachthehooktotheloadensuringthatthesafetybaris
fullyclosed(Pic.4.1).
Press the upper half of the control switch to raise the load
(Pic.5.1).Pressthelowerhalfofthecontrolswitchtolower
theload(Pic.5.2).
Theswitchisalsofittedwithanemergencystopbutton.In
theeventofanemergency,tostopthehoistimmediately,
hittheemergencystopbutton(Pic.5.3).Thiswillactivate
themechanicallockoftheemergencybutton,thatprevents
themachinefrombeingswitchedonuntilthemechanical
lockhas been released. To releasethe mechanicallock
twisttheemergencystopbuttoninaclockwisedirection.
Tocarryoutadoublelinelift(Pic.6),attachthesingleline
hooktothehoistframe(Pic.6.1).
Removethe screw(Pic. 7.1)from thedouble linepulley
andhook(Pic.7.2).Placethepulleyontothesteellifting
cable. Refit the hook and replace the screw (Pic. 7.3).
Ensurethepulleyrotatesfreely.
MAINTENANCE
Check the hoist regularly for damage and correct
operation.
Periodicallycheckthatthesteelcableisingoodcondition.
Damagedcables,asillustratedinpictureA,BandC,must
bereplacedimmediately.
Checkallsecuringscrewsarewelltightened.
Check the control switch operates correctly. Ensure the
hoiststopswhenthecounterweightliftsthecutoutarm.
Lubricatethesteelcableandotherexposedmovingparts
withalightcoatingofgrease.
TECHNICAL SPECIFICATION
NPECH250
Voltage 230V~50Hz
Ratedpower 550W
Mountingstructureloadcapacity 250 kg minimum
Elevatingspeed 4 m/min - 8 m/min
MaximumSafesinglelineloadcapacity 125 kg
MaximumSafedoublelineloadcapacity 250 kg
Elevatingheight(singleline) 12 m
Elevatingheight(doubleline) 6 m
Steelcablediameter 3 mm
Weight 12,25 kg
