E Actual position of the hood
The display will show the actual status of the wheel guard switch (OPEN or CLOSE)
F Indication if gauge arms are in the home position
GREEN = Gauge arm is located in home position
RED = Gauge arm is not in home position (also if gauge arm is not present or set out of
operation
G Status of the brake
The display will show the actual status of the brake (OPEN or CLOSE)
H Status of the QuickSpan
The display will show the actual status of the QuickSpan switch (OPEN or CLOSE)
K Actual shaft position
This value can lie between 0 and 255 and changes with the rotation of the shaft.
