Page 8 of 15
6. Putting the machine into operation
In order to set the machine into operation several general steps are required. The information on
the service functions can also be found in the instruction manual
DIGITAL WHEEL BALANCERS
Via the function key you get into the menu for service functions to select the basic
settings or change them according to the user’s requirements. The various menu functions from
F1 to F14 can be selected by pressing the +- keys
When you are in the function menu, an „Fn“ is shown on the left side of the digital display. The
chosen function is shown on the right side of the digital display.
Once a particular function is desired, it can be chosen by pressing the function key again
Perform the following steps in the order stated below
F 5 Calibration
The calibration weight supplied with the machine must be used
together with the clamping adapter. Make sure that the threaded hole
on the adapter is in line with the red indicator marking on the main
shaft.
For calibration the calibration weight (1987009WG3) is required
MACHINES with manual clamping of the wheel
Remove cone and clamp from the main shaft.
MACHINES with QuickSpan
:
Attach the pressure cup for steel rims to the clamping
sleeve and activate the QuickSpan
Press the function key to select the function menu.
Use +/- keys to select the Function 5.
Press function key again to activate the function.
