3
PART
REF. NUMBER PART DESCRIPTION
1 20125-00 Mounting Bracket
2 75999-00 Knockout Plate & Ground Screw
3 99270982 Receptacle
4 20126-02 Wiring Cover
5 04200-14 Keps Nut (2 Req.)
6 25083-01 Motor Bracket
7 02200-41 Motor
8 99020187 Fan Blade
9 03100-32 Screw, #8 Hex Washer Captive Hd.
(3 Req.)
10 99140187 Grille Spring
11 97009648 Grille Assembly
(Includes Key Nos. 10 & 11)
12 97009563 Charcoal Filter
PARTS LIST
1
2
3
4
5
6
7
8
9
10
11
12
