SERVICE PARTS
HL0450
B
E
AR1 SERIES RANGE HOOD
KEY NO.PART NO.DESCRIPTION
1 SR740014 3¼" X 10" ADAPTER/DAMPER
2 S99670656 LIGHT SWITCH (INCLUDING NUT)
3 S99670657 BLOWER SWITCH (INCLUDING NUT)
4
S600348 K
NOB, BLACK (SET OF 2)
S600349 KNOB, WHITE (SET OF 2)
5 S98012130 GRILLE COVER PLATE
6 S99080777 BLOWER ASSEMBLY (INCLUDING SCREWS)
7 S99010467 ALUMINUM FILTER
8 S98012128 ELECTRICAL COMPARTMENT COVER
* S97021380
NON-DUCTED FILTER
(FOR NON-DUCTED INSTALLATION ONLY)
* S99271677 BULB HOLDER WITH WIRES
* Not shown.
Order service parts by PART NO. - NOT by KEY No.
- 6 -
C
D
F
G
H
I
Replacement parts can
now be ordered on our
website. Please visit us at
www.Broan-NuTone.com
REPLACEMENT PARTS AND REPAIRS
In order to ensure your unit remains in good working condition, you must
use Broan-NuTone LLC genuine replacement parts only. Broan-NuTone
LLC genuine replacement parts are specially designed for each unit and
are manufactured to comply with all the applicable certification standards
and maintain a high standard of safety. Any third party replacement part
used may cause serious damage and drastically reduce the performance
level of your unit, which will result in premature failing. Broan-NuTone
LLC recommends to contact a certified service depot for all replacement
parts and repairs.
