NuTone PK22 - Service Parts

- 29 -
KEY NO. PART NO. DESCRIPTION
9 B08087189 Grease Filter
14 B02300233 Motor Capacitor
26 B02300899 Halogen Lamp Bulb
37 B02300787 Heat Sentry
39 B03294033 Electrical Cover
42 B03295001 Ductfree Filter Bracket
48 B02310201 Motor
49 B03295071 Blower Wheel
53 B03202007 Rubber Washer
56 B03292465 Discharg Collar
57 B02011004 Non-return Flap
68 B02011064 Right Blower Housing
69 B02011063 Left Blower Housing
115 BE3334250 Wiring Box
116 BE3334252 Wiring Box Cover
144 B03292287 Wire Clamp
147 BR2300135 Junction Clamp
165 B03294781 Electrical Box
165 B03295008 Circuit Board Box
166 B08086668 Circuit Board
195 BE3404074 Lamp Support (PK2229 model)
195 BE3404076 Lamp Support (PK2238 model)
230 B03292937 Switch Board Box Cover
234 BE3341636 Controls Protection
250 B02009102 Ring Nut
998 B080810511 Hardware Package
ALA B06108800 Halogen Support Assembly
* B06002008 Blower Assembly
(Includes Key Nos. 69, 68, 48, 49, 53, 42)
* B06107567 Switch Box Assembly
(Includes Key Nos. 222, 223, 224, 225, 226,
228, 229, 230)
* B08085018 Ductfree Collar Assembly
(Includes Key Nos. 56, 57)
* Not shown assembled.
SERVICE PARTS
MODEL PK22
