INSTALLING A NEW BAG
1. Open bag out at pleats and drop into detached pail
(FIGURE 10).
2. Reattach pail to unit using the handles.
3. Open the direct door and make sure bag holder is in
down position (FIGURE 11).
4. Reach bag through door access and slide cardboard tab
on to bag holder (FIGURE 12). Bag is fully engaged
when front edge of cardboard and holder are aligned
flush (FIGURE 13).
5. Lift holder back into place, bag will lock into place
automatically (FIGURE 14).
6. Close door and push
Reset button on control panel. Light
on unit will change back to green on the VX550 &
VX1000 (FIGURE 15).
Replacement bags may be purchased from your local
NuTone Sales Outlet. For a NuTone Sales Outlet near you,
call toll free 1-800-543-8687 or visit www.nutone.com and
click on Dealer Locator tab.
6
FIGURE 10 FIGURE 11 FIGURE 12
FIGURE 13 FIGURE 14 FIGURE 15

NuTone VX550 Specifications

General

AC input voltage	120 V
Maximum input power	- W
Cord length	1.8 m
Material	Thermoplastic
Type	Drum vacuum
Cordless	No
Cleaning type	Dry
Dust capacity	35.23 L
Product color	Black, Grey, Red
Tube material	Plastic
Dust container type	Dust bag
Proper use	Home
Vacuum air filtering	-

Weight and Dimensions

Depth	444.5 mm
Width	292.1 mm
Height	990.6 mm
Weight	- g
