NUTOOL BTL212 - Laser Specification; Laser Specification Details; Technical Specifications; Machine Technical Data

30
GB
LASER SPECIFICATION
BTL305 – BTL212
BTL250
Laser Class
Class 2
Classe 2
Laser Source
Laser Diode.
Laser Diode.
Laser power
Max 1.5mW
Max 1.5mW
Wave Length
635-670nm
635-670nm
Voltage
3V CC
4.5 V
Battery Type
2 x AAA
-
TECHNICAL SPECIFICATION
BTL305
BTL212
BTL250
Voltage
230V~50Hz
230V~50Hz
230V~50Hz
Motor
1900W
1200W
1800W
No load speed
4200 min-1
5000 min-1
5000 min-1
Saw blade size
305 x bore 25,4mm
210 x bore 30mm
254 x bore 25,4mm
Max cut at 90°
200 x 80mm
60 x 120mm
100 x 78mm
Max compound mitre cut at 45° x 45°
170 x 55mm
40 x 80mm
67 x 50mm
Max mitre cut at 90° x 45°
80 x 170mm
60 x 80mm
78 x 67mm
Max bevel cut at 45°
200 x 55mm
40 x 120mm
100 x 50mm
Sound Pressure
Lp 95.8 dB(A)
Lp 93,1dB(A)
Lp 93,1dB(A)
Sound Power
Lw 108.8 dB(A)
Lw 106,1dB(A)
Lw 106,1dB(A)
Vibration Level
2,5m/s2
1,5m/s2
1,5m/s2
Weight
14 kg
6,5 kg
10 kg
