TRANSPORT
Turn off the power tool before any transport and
disconnect it from the power supply.
Apply the power tool at least with two people, do not
touch the table extensions.
Protect the power tool from knocks, bumps and
strong vibrations, such as during transport in vehicles.
Secure the power tool against overturning and sliding.
Never use the safety devices for handling or
transporting purposes.
MAINTENANCE
Warning! Prior to any adjustment, maintenance or
servic
e work disconnect the mains power plug.
Keep all safety devices, air vents and the motor
housing free of dirt and dust as far as possible. Wipe
the equipment with a clean cloth or blow it down with
compressed air at low pressure.
We recommend that you clean the equipment
immediately after you use it.
Clean the equipment regularly with a damp cloth and
some soft soap. Do not use cleaning agents or
solvents; these may be aggressive to the plastic parts
in the equipment. Ensure that no
water can get into
the interior of the equipment.
In order to extend the service life of the tool, oil the
rotary parts once monthly. Do not oil the motor.
BRUSH INSPECTION
In case of excessive sparking, have the carbon
brushes checked only by a qualified electrician.
Important. The carbon brushes should not be
replaced by anyone but a qualified electrician.
STORAGE
Store the device and its accessories in a dark, dry and
frost-proof place that is inaccessible to children. The
optimum storage temperature is between 5 and 30˚C.
Store the electrical tool in its original packaging.
Cover the electrical tool in order to protect it from
dust and moisture.
When the sawblade and key are not in use, they can
be stored as in Fig 23.
Store the operating manual with the electrical tool.
TECHNICAL SPECIFICATION
Voltage 230V - 50Hz
Rated input
No load speed 4800min
-1
Blade size Ф254xФ30x2.8 mm
No. of teeth 24
Thickness riving knife 2.5 mm
Table size 546 x 630mm
190 x 630mm
190 x 630mm
250 x 540mm
Left extension table size
R
Rear extension table
ight extension table size
Cutting range 0-45º
Cutting height 0º 87mm
Cutting height 45º 55mm
Suction port Ø40mm
Operating height 1020mm
Sound Pressure Level L
pA
93.5dB(A)
K=3dB(A)
Sound Power Level L
WA
106.5 dB(A)
K=3dB(A)
Weight 20.7 kg
