-31-
TO CONNECT WITH NURSE CALL OR PDMS
Hold the ‘+’ key down and press “ON/OFF” for 2 seconds. The pump enters the set up mode. Press the “FILL SET” key to switch to the next setting:
“OUTP PDMS” (+) to connect with a Patient Data Monitoring System. “OUTP NRSE” to connect with a NURSE CALL system. Use the “+” or “-” key to
change to setting from “OUTP PDMS”, to “OUTP NRSE” or “OUTP OFF” and vice versa.
Press the key and keep it pressed for 2 seconds to exit the SET UP mode and turn off the pump. The settings are automatically saved.
OUTP NRSE
–
OUTP PMDS
+
fill set
2 sec
“LITE ON” (+) the light of the LCD remains on when the pump is connected to the mains. “LITE OFF” (-) the light of the LCD switches off after a few
seconds even if connected to the mains. Use the “+” or “-” key to change the setting from “LITE ON” to “LITE OFF” or vice versa.
EN
