~ 11 ~
Install TOP HINGE with HEX BOLTS (B)
NOTE :
Adjust nal position of the door
before tightening the bolts and
move cellar into place, leaving
4” clearance all around cellar.
MAKE SURE CABINET IS AIRTIGHT!
Adjust the level by turning
(counter clockwise) the LEGS (F)
as needed. Use a carpenter’s level.
STEP 7 : DOOR INSTALLATION
Insert DOOR onto BOTTOM HINGE
1
2
1
2
B
C
F
