Air Filter Assembly
The OxyPure
®
comes with four different preassembled filters inside the unit (see
diagram above). Each filter is labeled with a number. Match these with the slot numbers
when installing the filters. When the filters require cleaning, please refer to Cleaning &
Maintenance.
ASSEMBLY
Open Close
Access to Filters
Stainless Steel
Pre-Filter
Bio-Guard
®
Filter 1 Ozone Emission
Removal Filter
4
3
2
1
4321
Bio-Guard
®
Filter 2
1
2
3
4
Before Use:
1. Make sure the OxyPure is unplugged. Open the
Filter Slot Cover on the back to expose the lters.
2. Remove all tape and pull the lters from their slots using
the tabs or handles.
3. Remove the plastic wrapping from the Stainless
Steel Pre-lter and the Ozone Emission
Removal Filter. (Bio-Guard
®
lters are not
wrapped.)
4. Fully reinsert the lters into the Oxypure and close
the Filter Slot Cover.
5. Remove the sticker from the control panel.
