The MEC Series Pumps
Model-Specic Information
for the
MEC 5000/P
MEC 6500/P
MEC 8000/P
MEC Series Pump Specications
Model Number 5000 6500 8000
RPM Range 800–1400 800–1400 800–1400
Max. Air Flow-CFM 195 250 285
Max. Intermittent Vacuum 27 27 27
Max. Intermittent Pressure 30 30 30
Pump Drive Rotation CW/CCW CW/CCW CW/CCW
Porting Size 3 inch 3 inch 3 inch
Manifold With Four Way Valve Std Std Std
Oil Tank Capacity-Quarts 2 1/2 3 1/4 4
Bearings Sealed From Pump Interior Std Std Std
Anti-Spin Check Valve Std Std Std
Automatic Lubrication System Opt Opt Opt
Net Weight 308 343 400
