The S-Video output connector is used to send video signals to S-Video
compatible display devices. S-Video technology uses separate channels for
colour and brightness providing sharper, clearer images for display devices.
Connect the S-Video cable to the card and the display device, making sure that
both ends are secure before you power on the system and monitor.
DVI Connector
The DVI (Digital Visual Interface) connector uses DVI technology to provide high
speed digital video signals for digital display devices such as flat panel LCD
displays. Connect the monitor cable to the DVI connector on the card, making
sure it is secure before turning on the power. See the monitor documentation for
further configuration options.
Chapter 2. Hardware and Software Installation
