Nvidia GeForce2 Ti SP6600Ti - GeForce2 Ti Board Outline; 32 MB DDR SDRAM Models (SP6600 TI;32 M, SP6600 TI;32 M-TV); 64 MB DDR SDRAM Models (SP6600 TI;64 M, SP6600 TI;64 M-TV)

4
2. GeForce2 Ti Board Outline
2.1 GeForce2 Ti using DDR SDRAM (SP6600TI/32M, SP6600TI/32M-TV)
32M on board – 2Mx32 DDR SDRAM x 4
DVI
S-VIDEO
DB15
14.318MHZ
NOTE 1: TV output connector and TV encoder are reserved for optional
NOTE 2: DVI connector and LCD encoder are reserved for optional
NVIDIA
GeForce 2
Ti
BIOS
2M*32 2M*32
2M*32
2M*32
Power
LCD
Encode
TV
Encoder
