NVX VMPS35 - Installation Overview

4.5 in
4.1 in
0.8 in
1.2 in
4.9 in
Rear Camera Input
WIRED REMOTE
SUB OUTPUT
BACK
REAR RCA OUTPUT
BLACK
WARNING!
Before installing this unit onto any panel, ALWAYS ensure that there is
sufficient clearance behind the panel and that no wiring harnesses, fuel
lines, or any other critical components are exposed or damaged by the
installation. NEVER risk damaging the when cutting your opening.
INSTALLATION OVERVIEW
4
