NVX VSW82V2 - Specifications

Visit: nvx.com | Call: 213.444.1689 | 15303 Ventura Blvd. 9th Floor, Sherman Oaks, CA 91403
2
SUBWOOFERS
SPECIFICATIONS
Results vary based on enclosure type and volume. See pages 4 and 5.
A
B
D
C
Model Number
VSW82V2 VSW84V2 VSW102V2 VSW104V2 VSW122V2 VSW124V2 VSW152V2 VSW154V2
Power Range (RMS) 250-400 Watts 250-400 Watts 350-500 Watts 350-500 Watts 450-600 Watts 450-600 Watts 600 - 750 Watts 600 - 750 Watts
Impedance
per Voice Coil
2 Ohms 4 Ohms 2 Ohms 4 Ohms 2 Ohms 4 Ohms 2 Ohms 4 Ohms
Frequency Response 20-200 Hz 20-200 Hz 20-200 Hz 20-200 Hz 20-200 Hz 20-200 Hz 20 - 200 Hz 20 - 200 Hz
Xmax 9 mm 9 mm 11 mm 11 mm 12 mm 12 mm 12 mm 12 mm
Fs 53 Hz 53 Hz 30 Hz 30 Hz 25 Hz 25 Hz 23 Hz 23 Hz
Vas 6.65 L 6.65 L 27.73 L 27.73 L 66.24 L 66.24 L 179.78 L 179.78 L
Sd 20.11 20.11 33.00 33.00 49.08 49.08 85.50 85.50
Qts 0.595 0.595 0.476 0.476 0.396 0.396 0.489 0.489
SPL (1W/M) 85 85 87 87 90 90 92 92
QES 0.694 0.694 0.537 0.537 0.437 0.437 0.532 0.532
Net Weight 12.04 lbs (5.45 kg) 12.04 lbs (5.45 kg) 13.15 lbs (5.95 kg) 13.15 lbs (5.95 kg) 15.58 lbs (7.05 kg) 15.58 lbs (7.05 kg) 16.90 lbs (7.65 kg) 16.90 lbs (7.65 kg)
A Overall Diameter
8.50” (216 mm) 10.35” (263 mm) 12.44” (316 mm) 15.47” (393 mm)
B Mounting Diameter
7.82” (198.50 mm) 9.65” (245 mm) 11.63” (295.50 mm) 14.69” (373 mm)
C Cutout Diameter
7.20” (183 mm) 9.15” (236 mm) 11.12” (282.50 mm) 14.06” (357 mm)
D Mounting Depth
4.37 ” (111 mm) 5.00” (127 mm) 5.95” (151 mm) 6.83” (173.50 mm)
