07
KRAKEN X RGB SERIES
CORRECT
INCORRECT
D
2.1 PREPARATION - INTEL LGA 1200/115X/1366
STEP 2 - INSTALLING THE BACKPLATE
Install the Intel backplate on the rear of the motherboard as
oriented in the picture. Please ensure the sliders fit into the
mounting holes and the backplate of CPU socket fit within the
cut-out of the Intel backplate.
D
