・Connect the tube from the Fuel pressure sensor unit to the Injector joint nipple. Use a Hose clamp. It is
a must.
・Cut off an end of the tube when it is difficult to pull out from a nipple. Do not pull and twist the tube
strongly to pull it out. Do not give damage to a nipple when you use a nipper or a knife to cut the end of
the tube.
Installation
Be sure to use [Code No. 28382303 FLUORINE
(ETFE) RESIN TUBING (2m)] .
・Once a tube is connected to a nipple, an end of the tube is expanded and deformed. Cut the end when
you use the same tube again.
From fuel pressure sensor unit
Hose clamp
Injector coupler
CUT
CUT
To Next Page
