O.S. engine GF40U-FI - Installation: Generator

・
Mount the Generator after mounting the engine.
Installation
14
・The position of the generator (OGA-100A) is choosable from the three positions shown above.
Right side left side
Lower
M4x30 Bolt
M4x25 Bolt
4.5mm Spacer
15mm Spacer
Use four screw holes for each depending
on the mounting position.
Generator
